1060 H18 3003 H24 Curtain Wall Color Aluminum Coil PE or PVDF Coating
| Place of Origin | Zhengzhou Henan |
|---|---|
| Brand Name | Henan Yongsheng |
| Certification | ISO, RoHS |
| Model Number | Curtain Wall Color Aluminum Coil |
| Minimum Order Quantity | 2-3 tons |
| Price | FOB, CIF, CFR, CNF, etc. |
| Packaging Details | Seaworthy Export Standard Wooden Box |
| Delivery Time | 7-25 days after order confirmation |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 5000 tons per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Alloy | 1060 3003 | Temper | H18, H24, Etc |
|---|---|---|---|
| Thickness | 0.4-1.5mm | MOQ | 2-3 Tons |
| Width | 800-2000mm | Surface | PE/PVDF |
| Application | Color Aluminum Coil For Curtain Wall | Coating | Single And Double Sided Coating |
| Highlight | PE Color Aluminum Coil,PVDF Color Aluminum Coil,Curtain Wall Color Aluminum Coil |
||
Product Description
1060 H18 3003 H24 Curtain Wall Color Aluminum Coil with PE or PVDF Coating
Coated aluminum coil is a high-performance composite material manufactured by applying multiple layers of organic coatings to aluminum coil surfaces, followed by color coating and baking for curing. The surface-colored aluminum alloy coil offers exceptional stability and corrosion resistance, with color retention guaranteed for at least 8 years. This material features low density, high hardness, and lightweight properties.
Color coated aluminum coil combines the advantages of aluminum coil and organic materials, offering high mechanical strength, excellent toughness, easy processing and forming capabilities, along with superior coloring, decorative appeal, and corrosion resistance from organic polymer coatings. The material is easily punched, bent, deep drawn, and welded, resulting in practical, workable, and durable end products.
Coating Specifications
Epoxy Resin Primer
- Excellent adhesion to diverse substrates
- Superior chemical resistance in harsh environments
- Outstanding corrosion resistance
- High compatibility with various topcoats
- Exceptional wear resistance
- Superior rheological properties on coil coating lines
Polyester Resin Topcoat
- Excellent film properties with high flexibility and hardness
- Superior processability and workability
- Optimal leveling on coil coating lines
- Strong adhesion and chemical resistance
- Exceptional weather resistance
Epoxy Resin Backcoat
- High-quality film properties with excellent hardness
- Superior scratch resistance and processability
- Optimal leveling on coil coating lines
- Excellent adhesion to various substrates
Product Specifications
| Specification | Details |
|---|---|
| Aluminum Alloy | 1050, 1060, 1100, 3003, 3004, 3105, 5052, 5083, etc. |
| Temper | H12, H14, H16, H22, H24, H26, O, H112 |
| Thickness | 0.2mm - 3.0mm |
| Width | 30mm - 1600mm |
| Coil ID | 505 mm |
| Single Weight | 2.5-ton roll or customized |
| Coating Thickness | PE coating ≥ 18μm / PVDF coating ≥ 25μm |
| Color Options | Solid/metallic colors, wooden/marble patterns |
| Paint Quality | Premium brands (PPG, BECKER, AkzoNobel, etc.) |
| Minimum Order Quantity | 2-3 tons (depending on specifications) |
| Production Capacity | 100,000 Tons/Year |
| Packaging | Export wooden pallet |
| Applications | Raw material for ceilings, aluminum composite panels, aluminum sheets, aluminum sign boards, kitchen cabinets, display platforms, decoration, and wall cladding |
